Button	WPS/Reset Button
Dimensions ( W x D x H )	182 × 128 × 35 mm
Ports	1 x 10/100Mbps WAN Port // 4 x 10/100Mbps LAN Ports
Antenna Type	Fixed Omni Directional Antennas
Antenna Gain	2 x 5dBi
Wireless Standards	IEEE 802.11n/b/g 2.4 GHz
Signal Rate	11n: Up to 300Mbps // 11g: Up to 54Mbps // 11b: Up to 11Mbps
Reception Sensitivity	270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER
Frequency	2.4-2.4835GHz
Transmit Power	<20dBm (EIRP)
Wireless Modes	Router Mode // Access Point Mode // Range Extender Mode
Wireless Security	64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
SOFTWARE	Protocols: IPv4, IPv6 // Parental Controls: URL Filtering, Time Controls // WAN Types: Dynamic IP, Static IP, PPPoE, PPTP and L2TP // Quality of Service: QoS by Device // NAT Forwarding: Port Forwarding, Port Triggering, DMZ and UPnP // IPTV: IGMP Proxy, IGMP Snooping // DHCP: Address Reservation, DHCP Client List, Server // DDNS: NO-IP, Comex, DynDNS // Management: Tether App, Webpage Check Web Emulator>
System Requirements	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser // Cable or DSL Modem (if needed) // Subscription with an internet service provider (for internet access)
Package Contents	TL-WR840N 300Mbps Wireless N Router: The main device providing wireless connectivity. // Power Adapter: Supplies power to the router. // Quick Installation Guide: A manual to assist with setup and configuration. // Ethernet Cable: Used for wired connections to devices or a modem. // Resource CD: Contains the user guide and other helpful information.
Certification	CE, FCC, RoHS
Operating Temperature	0℃~40℃
Storage Temperature	-40℃~70℃
Operating Humidity	10%~90% non-condensing
Storage Humidity	5%~90% non-condensing

TP-Link TD-W840N Wireless N Access Point – 300Mbps, 2.4GHz, Wi-Fi Router Mode

Product Description
