*Product Name*	*Triton 850Rx*
*MODEL No.*	*SST-TR850R-GF*
*Color*	*Black (lead-free paint)*
*FORM FACTOR*	*ATX (PS2) - ATX 3.1 Compatible*
*CERTIFICATION*	*Cybenetics Gold*
*MAX. DC OUTPUT*	*850W*
*COMBINED +3.3V & +5V*	*100W*
*COMBINED +12V*	*850W*
*Power Density*	*470.7 W/L*
*INPUT VOLTAGE*	*90 ~ 264 Vrms*
*INPUT FREQUENCY RANGE*	*47Hz ~ 63Hz*
*PFC*	*Active PFC（PF>0.9 at full load）*
*EFFICIENCY*	*87% ~ 89% overall efficiency*
*MTBF*	*100,000 hours*
*PROTECTIVE CIRCUIT*	*OCP/OVP/OTP/OPP/SCP/UVP*
*CONNECTORS*	1 x 24 / 20-Pin motherboard connector // 2 x 8 / 4-Pin EPS / ATX 12V connector // 1 x 12+4-Pin 12V-2x6 connector // 5 x 8 / 6-Pin PCIe connector // 6 x SATA connector // 2 x 4-Pin Peripheral connector
*Cooling System*	*Single 120mm ICB bearing fan*
*FAN NOISE LEVEL*	*18 dBA min.*
*Operating Temperature*	*0°C ~ 40°C*
*Weight*	*1.56 kg*
*DIMENSIONS*	*150mm (W) x 86mm (H) x 140mm (D)*

SilverStone Triton 850Rx SST-TR850R-GF — 850W, ATX 3.1 PCIe Gen5, Cybenetics Gold
